Technical data:
Material - anodized aluminum
Control - smooth power control by changing the voltage 0V to 12V, E / O connector
Power supply - branded Li-ion batteries, 4S package
Depth - each reservoir is tested to a pressure of 1.6 MPa (guaranteed 150 m)
Dimensions - 330 mm x 70 mm
Weight - 2.4 kg
Weight in water 1 kg
Load - E / O port 180 W max, RCA port 80 W max - designed to charge and power the flashlight
- Protection - All Miranda batteries have overcharge, deep discharge, overload and short circuit protection
- RCA connector unregulated - voltage the same as on the battery pack.
The standard length of the E / O cable is 60 cm, please let me know and provide the size of the cable, if it is to be different than the standard one, you can do it while completing the order in the box:
Comment on the order
Miranda batteries are compatible with the Heating system santi, northern diver heated vest and many other 12 V max working units
recommended for santi heated undersuit, HEATED UNDERSUIT FLEX 2.0, santi bz 400 heated
Charging current max 5 A in the 4S li-ion standard
the charger is not included in the price of the battery
attention
In heating batteries, Miranda introduced second-generation controllers that provide voltage regulation from 0V to 12V in the full range of battery capacity. The new Miranda controllers maintain the set heating power despite the voltage drop on the battery. It is a breakthrough in powering heating systems that guarantees full power until the battery is exhausted, thus eliminating the effect of weakening heating during diving associated with discharge and voltage drop.
If you use a 14.8 V (4 S) heating system, e.g. Heizteufel, you can order a battery with a first generation controller. The regulation is then in the range of 0 V to the voltage on the battery. Average 14.8 V.
