Xtar MC6 II Li-ion charger

Features and capabilities of the charger

• Charges Li-ion batteries with a three-stage TC / CC / CV charging process.
• It has six independent charging channels.
• It has a LCD display that informs about the current and voltage of the charging cell.
• Informs about the current used for charging.
• Possibility of measuring cell capacity.
• Powered by any power supply unit with a USB socket or from a USB port on your computer.
• Possesses the function of reactivating a deeply discharged cell.
• Protections: short-circuit, thermal, reverse polarity.

Technical specifications of the charger

• Power supply: 5 V DC / 3 A
• Supported Li-ion batteries of any capacity:
• 1 to 4 pieces: 10440, 14500, 14650, 16340, 17500,17670, 18350, 18500, 18650, 18700, 22650, 25500, 26650,32650
• only in the two outermost channels: 26650 and above
• Charging methods
• Li-ion - processor controlled TC / CC / CV
• Charging current: dependent on one or two power supplies.
• Clear LCD display
• Protection against overheating of the charger and batteries
• Overload / short-circuit protection
• Reverse polarity protection
• Button to switch between channels.
• Dimensions: 111 x 148 x 34 mm
• Weight: 200 g
• Included: USB - DC 5.5 x 2.5 mm cable.
